Uteco Jade 641 year 1991
Uteco Jade 641 year 1991 is a 6 color central drum flexo printer for paper. It is suitable for paper from 40 – 150 gsm.
Uteco Jade 641 year 1991
- Brand: Uteco
- Model: Jade 641
- Year: 1991
- With gears
- 6 colors
- Max. material width (50mm more than the model): 1350 mm
- Maximum print width equal to the model: 1300 mm
- Min – max print length: 400 – 1500 mm
- Material thickness: 40 – 150 gsm
- Unwinder and rewinder diameter: 1300 mm
- Plate thickness: 0.112.
- Maximum print speed: 300 m/ min.
- Reel core diameter: 76 mm
- Mechanical speed: 150 – 250 m/min
- Camera based BST Eltromat system to monitor defects, quality, register.
- Water based inks
- Manual or semi-automatic registration and set-up
- External shoulder length 550mm larger than the standard model.
- Gas drying system
- Printing cylinders (48 in total):4 x 600, 6 x 840, 6 x 860, 6 x 890, 6 x 910, 6 x 950, 6 x 980, 4 x 1010, 4 x 1040 mm
- Geared module 10mm, helical 3.183 – pressure angle: 20⁰
- Electrical power Volts 200/400v (380v) – 60HZ – 3 phase.
- Installed power volts 298.5kw-current 5AMP.
- Visible in production
Italian brand
For over 35 years, Uteco Group have offered printing and converting solutions that anticipate market changes, believing in the values of innovation, flexibility and sustainability. The most important milestones in Uteco Group history are closely linked to the manufacturing of particular innovative solutions for printing and converting, both for Italian customers and European, American and other markets.
Uteco offers 4 main platforms of CI flexo presses: Diamond, Crystal, Onyx and Topaz, each one thought and design to best suit different market segments each with features and innovative solutions thought for each segments.
