La Meccanica Fumagalli cah roll slitter rewinder TRL-AR year 2003
La Meccanica Fumagalli TRL-AR from 2003 is a cah roll slitter rewinder. The machine will be refurbished and with guarantee.
La Meccanica Fumagalli cah roll slitter rewinder TRL-AR year 2003
- Brand: La Meccanica Fumagalli
- Model: TRL-AR
- Year: 2003, completely refurbished
- Paper grammage: 20 – 600 gsm
- Maximum parent roll working width: 1100 mm
- Maximum unwinding diameter: 1200 mm
- Maximum rewinding diameter: 420 mm
- Minimum cutting width: 18 mm
- Maximum speed: 350 m/min
- Rewinding system:
- 2 rewinding shafts diameter 50 mm, for cores with inner core diameter 50,5 mm
- Unwinding system:
- Automatic electronic meter counter with double selection for automatic programmed stop with pre-deceleration
- Pneumatic disc brakes with automatic tension control
- Pneumatic expandable unwinder for 76 mm cores
- Axial displacement device for parent roll adjustment during operation
- Front handwheel adjustment for operator use with ±20 mm movement
- With pneumatic lifter for parent rolls
